Fully Automatic High-Speed UV Inkjet One-pass Board Printing Production Line

• Fast print speed: 11s~23s/piece
• High precision up to 0.02mm adjustable error, 600dpi
• Sharp tiny text & scannable micro QR codes, variable data support
• Print gloss & matte on same substrate in one pass
• Pre-reserved 6-color channel for white ink / spot color / varnish upgrade
• Double-sided printing with 0.2mm accurate registration
• Non-contact printhead cleaning to extend head service lif
• 30% higher precision, 40% less UV ink consumption

• One pass digital inkjet printer is use passhtrough technology,same as Single-Pass Digital Printers,
  Our single-pass UV printer systems are designed to print directly onto products and substrates in one continuous pass, making them ideal for manufacturers producing packaging, corrugated,sign graphic, materials, labels, coated sheets, and industrial components.  Dreams120  can printing 1220mmX2450mm with one pass graphic in 3sec.

• What is a Printing Pass? A "Pass" refers to the number of times the printhead carriage travels over the same horizontal area to complete the ink coverage. Low Pass (e.g., 2 pass,4 Pass 6pass): The printhead covers the area in fewer strokes. This results in the highest printing speed but lower ink density and detail. xenons dreams 1225 can printing with one pass also can printing in 2or 4or 6 pass for  different  graphic quality .

What are the differences between a single-pass printer and a traditional scanning printer?

With the rapid development of industrial digital printing technology, the variety of printing equipment is becoming increasingly diverse. In packaging printing, decorative building materials, advertising production, and industrial manufacturing, single-pass printers and traditional scanning printers are two common types of equipment. Although both can complete image printing tasks, there are significant differences in their working methods, production efficiency, application scenarios, and equipment structure. For enterprises, understanding the characteristics of these two types of equipment helps in choosing a more suitable solution based on actual production needs.

Dreams Onepass printer Significant Differences in Working Principles

• Single-pass (one-pass)printers and traditional scanning printers differ significantly in their operating mechanisms. Single-pass (onepass)printers use a full-width coverage printhead layout. During printing, the printhead remains fixed, and the material continuously advances through the conveyor system.
•  The image is printed in one pass as it passes through the printhead area, thus enabling high-speed continuous production. Traditional scanning printers, on the other hand, rely on the printhead carriage moving back and forth, scanning line by line to complete the pattern output. This requires repeated movement after each section is completed, resulting in a relatively longer overall printing time.


• In actual production processes, single-pass printers are more suitable for large-scale, high-efficiency industrial production needs, while scanning printers, with their higher flexibility, are often used for small-batch, diversified, and personalized customization. These different working modes determine the differences in production efficiency, application areas, and equipment configuration between the two types of equipment.

How Many Advantages of OnePass industry printers ?

Compared to scanning printers, single-pass printers have the following characteristics:

• Faster printing speed, suitable for large-scale continuous production.
• Higher production efficiency, reducing equipment waiting time.
• Higher degree of automation, facilitating intelligent management.
• Stronger operational stability, suitable for long-term operation.
• Easier to integrate into industrial production lines.

These characteristics make OnePass industry printers  an important piece of equipment in the industrial printing field.

• And typically, there are four main types:

What is Differences in Print Quality and Production Efficiency

In terms of printing quality, both types of equipment can achieve high-precision output, but the methods of achieving this different. Scanning printers, due to their multiple-pass printing, can improve detail by increasing the number of print passes, thus having an advantage in some high-precision customization scenarios. Single-pass printers, on the other hand, rely on high-density printhead arrangement  High Reselotion Printheads to achieve high-resolution output, maintaining image quality while achieving higher production speeds.

How To Choose OnePass industry printers  and Scnning Printer?

From a production efficiency perspective, the difference between the two is even more pronounced. OnePass industry printers  can achieve continuous, non-stop production, making them suitable for long order tasks; scanning printers require multiple scanning actions during the printing process, resulting in a relatively slower overall production speed. The efficiency difference becomes more significant as order sizes increase. One-pass printer normally for Industry market,scanning printer work for sign market.

Suitable Application Scenarios for Each Type of Equipment

Different production needs correspond to different equipment choices:

Single-pass(onepass) printer:

• The packaging and printing industry tends to use single-pass （onepass）printers.
• High-speed OnePass industry printers printing solutions are suitable for corrugated cardboard box production.
• OnePass （single-pass)printers are ideal for the architectural decorative materials sector. Boasting massive market demand, this industry requires fast turnaround and short lead times.



• Scanning printing equipment is commonly used for customized advertising products.
• Scanning printing is more suitable for small-batch personalized orders.
• OnePass industry  equipment is generally chosen for industrial assembly line production.
  When purchasing equipment, companies need to evaluate based on product type and order size.

How Companies Choose the Right Equipment

Equipment selection requires consideration not only of print quality but also of production capacity needs, budget investment, and future development plans. For businesses facing large-volume order production, single-pass printers can help improve overall production efficiency and reduce unit production costs. For businesses primarily focused on customized business and small-batch production, traditional scanning printers offer greater flexibility. As industrial digitalization continues to advance, more and more large manufacturing enterprises are adopting single-pass (onepass)printing technology to build automated production systems, while scanning and printing equipment continues to maintain stable demand in the advertising, crafts, and personalized customization markets. Making a rational choice based on one’s own business characteristics is crucial to fully realizing the value of the equipment and maximizing production efficiency.

Jingping 3D Build: Multi-layer Decorative Backdrop

Material Combinations

• KT Board: Lightweight, low cost, easy cutting. Ideal for short-term events and one-off photo backdrops.
• PVC Foam Board: Rigid, waterproof, deformation-resistant and reusable. Suitable for corporate annual events and long-term mall decorations.
• 3D Fabrication: Multi-layer assembly, curved grooving, hollow carving, embossed relief, integrated light slot fabrication.

Full-scenario Coverage

• Festivals: Spring Festival, Dragon Boat Festival, Mid-Autumn Festival, National Day, Christmas, 520 / Qixi Festival
• Events: Birthday parties, baby showers, wedding welcome backdrop, friend gatherings, corporate team building
• Commercial: Store grand opening, mall market, exhibition booth, corporate annual meeting, new product launch

Service Advantages Free 3D renderings, modular split packaging, easy self-assembly without professional installers, local delivery & installation, 24h rush delivery, both sale & rental options.

Pain Points Solved vs Competitors

• Ordinary large-format printing: Flat, lack of depth, poor photo effect
• Traditional truss: Heavy and difficult transportation
• Acrylic 3D signs: Very high cost
• Jingping 3D Build: 3D visual effect + lightweight + cost-effective, balancing aesthetics and budget.
