CS8 PRO SUBLIMATION PRINTER

Printer Head:   8*EPSON I3200-A1
Printer Resolution:  3200DPI
Printer Speed:  340sqm/h
Printer Width:  1800mm
Printer Ink: Dye Sublimation Ink,Pigment Ink
Printer Media: Sublimation Transfer Paper ,Poster Paper
RIP Software: Maintop, Photoprint,Neostampa,Onyx,etc.

SPECIFICATION

CS8 Pro Digital Heat Transfer Printing Machine — High-Efficiency Production Solution for Textile Printing

Product Overview

The CS8 Pro Digital Heat Transfer Printing Machine is a cost-effective, high-speed production solution engineered specifically for the textile printing industry. With a 1.9-meter printing width and 8 Epson i3200 A1 high-precision printheads, it delivers high-speed mass production, long-term stability, and consistent color accuracy. Designed to meet the demands of apparel fabrics, home décor, and flag/banner manufacturing, this machine is the ideal choice for digital transformation in textile and home textile industries.

Product Features

   Epson l3200 Print Head

Equipped with eight Epson l3200-A1 print heads, the printing accuracy can reach 300 npi/row and 600 npi/2 rows. long durablility.
8 Print Heads Work together

Equipped with advanced electrical board system,
standard 8pcs i3200 print heads with a top speed of 360
sqm/h
Double heat dryer system

The double-layer infrared drying system provides precise
temperature and power control, ensuring optimal drying
efficiency for consistent print quality.

Variable frequency motor

With a variable frequency motor, the printer ensures smooth paper collection and release, reducing operational instability and enhancing printing efficiency.

Metal slotted front drive roller

The metal slotted front drive roller enhances paper feeding stability, preventing slipping and ensuring a consistent printing process for high-quality results.

Wider cabinet structure

The wider cabinet structure of the BH-1808TX provides a stable, durable frame that supports heavy-duty printing operations, improving machine longevity and reliability.

Dual THK mute guide rails
Featuring THK high-precision mute guide rails, the printer runs smoothly and silently, ensuring consistent print quality while reducing mechanical wear.
Jumbo roll media loading
Supports up to 1000mm roll media, enabling continuous and efficient printing with a rubber strip roller for precise material handling and neat release.
5L Bulk Ink Supply System
The 5L bulk ink supply system ensures continuous ink supply with a 400cc secondary cartridge, maintaining stable ink flow for high-speed, uninterrupted printing.



Core Highlights

✅ 1.9m Printing Width & 8 Epson i3200 Printheads

Efficient printing with industrial-grade reliability and color consistency, making it the top choice for digital upgrades in textile and home textile production.

✅ Dual Front & Bottom Infrared Heating System

Uniform heat distribution rapidly dries ink to prevent color bleeding. The energy-efficient design synchronizes printing and drying processes, eliminating secondary processing and streamlining production.


✅ Ultra-Stable & Silent Operation

Reinforced integrated aluminum plate structure with strengthened side panels and base beams maximizes rigidity. Paired with imported THK high-silent dual guide rails and magnetic levitation motors, the machine maintains minimal vibration and noise even at high speeds, guaranteeing precise inkjet performance and long-term durability.

✅ Constant Tension Control, Wrinkle-Free Output

Swing-arm tension rollers combined with precision angle sensors and servo-controlled motors enable micron-level tension regulation. Paired with a vacuum platform and 3-stage adjustable pressure rollers, it eliminates paper buckling and wrinkles during feeding, ensuring flawless media flatness and print quality.

✅ Siphon Ink Supply System

Standard 5L large-capacity continuous ink system with siphon technology ensures stable, long-duration ink delivery. Uniform droplet ejection enhances detail reproduction while minimizing ink interruptions and splatter.
✅ Versatile Material Compatibility

Supports heat transfer paper, titanium white paper, wall coverings, home textile fabrics, velvet, and other roll media.





Sublimation vs DTF Printing: A Complete Comparison

Understanding the differences between sublimation and DTF (Direct-to-Film) printing is essential when choosing the right solution for your custom printing business. Below is a detailed,
unbiased comparison to help you decide based on your fabric type, product range, and printing needs.

Feature Sublimation Printing DTF (Direct-to-Film) Printing
Compatible Fabrics 100% polyester or polymer-coated fabrics and substrates Cotton, polyester, blends, and more
Fabric Color Limitations Only for white or light-colored fabrics (no white ink) Works on light and dark fabrics (uses white ink)
Substrate Requirements Must be polyester-based or coated for proper dye bonding No coating required; prints on various fabric types
Application Range Apparel, mugs, metal, wood, signage (soft & hard), photo gifts Primarily textiles; some rigid items with film or primer
Print Durability Permanent dye - no cracking, peeling, or fading Durable - withstands washing and stretching
Feel of Print No hand feel - ink becomes part of the fabric Slightly raised texture - ink layer on surface
Color Vibrancy Vivid results on white/light polyester or coated items Rich, bold prints on all fabric colors
White Ink No - relies on white/light background color Yes - enables printing on dark surfaces
Production Process Print -> Press Print -> Apply Powder -> Cure -> Press
Maintenance Needs Low - minimal cleaning and simple operation Moderate to high - requires white ink circulation & powder management
Setup Costs Generally lower - basic printer and heat press setup Slightly higher - includes curing and powder equipment
Environmental Factors Clean - no powder, no fumes, low odor Requires proper ventilation due to powder curing
Best Use Cases Light polyester apparel, mugs, signage, gifts, photo panels T-shirts (any color), cotton bags, hoodies, dark apparel


Professional Sublimation Printer - Vibrant Prints for Polyester and Coated Surfaces

Unlock stunning color and long-lasting results with our high-performance Sublimation Printer. Perfect for polyester-based garments, photo panels, mugs, and soft signage or hard signage,
this printer delivers sharp, vibrant, and professional-grade output every time. With fast production speeds and a clean, efficient workflow, it's ideal for both startups and high-volume custom print shops.


Application

SP-S1808 Sublimation Printer


The machine is suitable for a wide range of products, including sportswear, cycling apparel, team jerseys, swimwear, home textiles, flags, advertising displays, and personalized gifts,
meeting diverse application needs
across apparel customization, advertising, home decoration, and personalized products.

Specification

Printer Model  CS8 PRO
Printhead Type EPSON I3200-A1
Nozzle Qty 8pcs printheads
Height to Platform 2-5mm
Printing Speed 1pass   340sqm/h
2pass   170sqm/h
Ink Color CMYK(Optional 8 Colors)
Type Dye Sublimation
supply method Siphoning
Max Printing Width 1800mm
Printing Media Transfer Paper
Media Transfer Method Auto air shaft feeding and take-up system
Drying Method External,Intelligent and air-heat Integrated drying system
Moisture Mode Fully sealed auto moisturing and cleaning
RIP Software Maintop6.0,Photoprint,Onyx,Wasatch and NeoStampa and etc.
Image Format JPG,TIF,PDF,BMP and etc.
Computer System WIN7 64bit/WIN10 64bit
Hardware Hard disk:500G (system disk more than 100G)
Memory:4G or more
CPU:Intel i5/i7 processor
Transmit Port Gigabit LAN
Work Environment Temperature 20-35 centi degree;  Humidity 35-65%
Power Input Voltage 210-230VAC
Printing system 10KW
Drying system Max power 6KW
Dimension Printer Dimension 3660*1100*1800mm
Packing Dimension 3720*1100*1990mm
Weight Net Weight 950KG
Gross Weight 1000KG
